The product is suitable for liquid, gas medium pipeline and equipment, and is used to connect and cut off the medium in the pipeline.
The sealing surface has the advantages of good sealing performance, easy operation, no damage to the sealing surface, long service life and no water hammer phenomenon.
Can be installed in any position of the pipeline, but the flow direction by pointing to the installation.
Clockwise turn of hand wheel means the closing of valve, otherwise it means opening, do not allow assistant lever to the hand wheel.
Valve body, Bonnet: Grey iron, Ductile iron
Stem：Carbon steel, Stainless steel
Disc: Grey iron, Ductile iron
Applicable Temperature: ≤200℃
Applicable Medium: water, Oil, Gas and corrosive medium
Main Material: Cast iron, brass, carbon, chrome-plated
Body Test: 1.5 times the working pressure with water. This test is performed after valve assembly and with disc in half position open, it is called as a body hydro test.
Seat Test: 1.1 times the working pressure with water.
Function / Operation Test: At the time of final inspection, each valve and its actuator (Flow-Control Lever / Gear / Pneumatic Actuator), under goes a complete operating test (Open/Close). This test carried out without pressure and at ambient temperature. It ensures the correct operation of the valve / actuator assembly with accessories such as solenoid valve, limit switches, air filter regulator etc.
Special Test: On request, any other test can be carried out according to special instruction by client.
1,The sealing surface has the advantages of good sealing performance, easy operation, no damage to the sealing surface, long service life and no water hammer phenomenon.
2,The product has reasonable structure, reliable sealing, excellent performance and beautiful appearance.
3,Stem after the modulation and surface nit riding treatment, has a good corrosion resistance and abrasion resistance.
4,The product can be used with standard pipe flanges and flange sealing surface in the form, to meet the needs of various projects and user requirements.
Valve design and manufacture according to GB/T12237-1989
Valve test according to GB/T13927-1992
|Applicable Medium||Water, Oil, Gas and corrosive medium|
|Main Material||Cast iron, brass, carbon chrome-plated)|
